1K101
5000m/Month
7226190000
| Quantity: | |
|---|---|
Product Details
Model | 1 K101, 2605SA1 |
Width | 142mm, 170mm, 213mm |
Thickness | 24±2um |
Lamination Fact | 87%~90% |
Saturation Magnetic Induction(BS) | 1.56T |
Core Loss(P) | <=0.13W/KG |
Excitation Power(Pe) | <=0.4VA/KG |
Product introduction
Applications: Mainly used to replace silicon steel sheets, as cores of power frequency distribution transformers and intermediate frequency transformers of various forms and different powers, working frequencies range from 50Hz to 10KHz; as core materials of high-power switching power supply reactor, the use frequency can reach 50KHz.
Properties and characteristics: Amorphous alloys have high saturated magnetic induction, high permeability, low coercivity, low loss (equivalent to 1/3-1/5 of silicon steel), low excitation current and good temperature and time stability.
Product Details
Model | 1 K101, 2605SA1 |
Width | 142mm, 170mm, 213mm |
Thickness | 24±2um |
Lamination Fact | 87%~90% |
Saturation Magnetic Induction(BS) | 1.56T |
Core Loss(P) | <=0.13W/KG |
Excitation Power(Pe) | <=0.4VA/KG |
Product introduction
Applications: Mainly used to replace silicon steel sheets, as cores of power frequency distribution transformers and intermediate frequency transformers of various forms and different powers, working frequencies range from 50Hz to 10KHz; as core materials of high-power switching power supply reactor, the use frequency can reach 50KHz.
Properties and characteristics: Amorphous alloys have high saturated magnetic induction, high permeability, low coercivity, low loss (equivalent to 1/3-1/5 of silicon steel), low excitation current and good temperature and time stability.
